PNOZ s11
Operating Manual PNOZ s11
21693-EN-11
| 16
Technical details
General 750111 751111
Certifications
CCC, CE, EAC (Eurasian),
KOSHA, TÜV, cULus Listed
CCC, CE, EAC (Eurasian),
KOSHA, TÜV, cULus Listed
Electrical data 750111 751111
Supply voltage
Voltage 24 V 24 V
Kind DC DC
Voltage tolerance -20 %/+20 % -20 %/+20 %
Output of external power supply
(DC) 3 W 3 W
Residual ripple DC 20 % 20 %
Duty cycle 100 % 100 %
Inputs 750111 751111
Number 1 1
Voltage at
Input circuit DC 24 V 24 V
Current at
Input circuit DC 95 mA 95 mA
Max. inrush current impulse
Current pulse, input circuit 2 A 2 A
Pulse duration, input circuit 0,1 ms 0,1 ms
Max. overall cable resistance Rl-
max
Single-channel at UB DC 30 Ohm 30 Ohm
Relay outputs 750111 751111
Number of output contacts
Safety contacts (N/O), instant-
aneous 8 8
Auxiliary contacts (N/C) 1 1
Max. short circuit current IK 1 kA 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1 EN 60947-4-1
Utilisation category of safety con-
tacts
AC1 at 240 V 240 V
Min. current 0,003 A 0,003 A
Max. current 6 A 6 A
Min. output 0,04 VA 0,04 VA
Max. power 1500 VA 1500 VA
DC1 at 24 V 24 V
Min. current 0,003 A 0,003 A
Max. current 6 A 6 A
Min. output 0,04 W 0,04 W
Max. power 150 W 150 W
