PNOZ s11
Operating Manual PNOZ s11
21693-EN-11
| 24
Operating height Permitted ambient temperature
3000 m 50 °C
4000 m 45 °C
5000 m 40 °C
Remove plug-in terminals
Procedure: Insert the screwdriver into the housing recess behind the terminal and lever the
terminal out.
Do not remove the terminals by pulling the cables!
Order reference
Product type Features Terminals Order no.
PNOZ s11 24 V DC Screw terminals 750111
PNOZ s11 C 24 V DC Spring-loaded terminals 751111
EC declaration of conformity
This product/these products meet the requirements of the directive 2006/42/EC for ma-
chinery of the European Parliament and of the Council. The complete EC Declaration of
Conformity is available on the Internet at www.pilz.com/downloads.
Authorised representative: Norbert Fröhlich, Pilz GmbH & Co. KG, Felix-Wankel-Str. 2,
73760 Ostfildern, Germany
