Pilz PNOZ s4.1 User Manual

PNOZ s4.1
Operating Manual PNOZ s4.1
21890-EN-15
| 28
Times 750124 750154 751124 751154
Supply interruption
before de-energisa-
tion 20 ms 20 ms 20 ms 20 ms
Simultaneity, chan-
nel 1 and 2 max. ∞ ∞ ∞ ∞
Environmental data 750124 750154 751124 751154
Climatic suitability EN 60068-2-78 EN 60068-2-78 EN 60068-2-78 EN 60068-2-78
Ambient temperat-
ure
Temperature
range -10 - 60 °C -10 - 60 °C -10 - 60 °C -10 - 60 °C
Storage temperature
Temperature
range -40 - 85 °C -40 - 85 °C -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during
operation Not permitted Not permitted Not permitted Not permitted
EMC EN 60947-5-1, EN
61000-6-2, EN
61000-6-4, EN
61326-3-1
EN 60947-5-1, EN
61000-6-2, EN
61000-6-4, EN
61326-3-1
EN 60947-5-1, EN
61000-6-2, EN
61000-6-4, EN
61326-3-1
EN 60947-5-1, EN
61000-6-2, EN
61000-6-4, EN
61326-3-1
Vibration
in accordance
with the standard EN 60068-2-6 EN 60068-2-6 EN 60068-2-6 EN 60068-2-6
Frequency 10 - 150 Hz 10 - 150 Hz 10 - 150 Hz 10 - 150 Hz
Amplitude 0,35 mm 0,35 mm 0,35 mm 0,35 mm
Airgap creepage
in accordance
with the standard EN 60947-1 EN 60947-1 EN 60947-1 EN 60947-1
Overvoltage cat-
egory III / II III / II III / II III / II
Pollution degree 2 2 2 2
Rated insulation
voltage 250 V 250 V 250 V 250 V
Rated impulse with-
stand voltage 4 kV 4 kV 4 kV 4 kV
Protection type
Housing IP40 IP40 IP40 IP40
Terminals IP20 IP20 IP20 IP20
Mounting area
(e.g. control cab-
inet) IP54 IP54 IP54 IP54
Mechanical data 750124 750154 751124 751154
Mounting position Any Any Any Any
Mechanical life 10,000,000 cycles 10,000,000 cycles 10,000,000 cycles 10,000,000 cycles
