Operating Manual PNOZ s4.1
21890-EN-15
| 29
Mechanical data 750124 750154 751124 751154
Material
Bottom PC PC PC PC
Front PC PC PC PC
Top PC PC PC PC
Connection type
Screw terminal Screw terminal
Spring-loaded ter-
minal
Spring-loaded ter-
minal
Mounting type plug-in plug-in plug-in plug-in
Conductor cross
section with screw
terminals
1 core flexible
0,25 - 2,5 mm², 24 -
12 AWG
0,25 - 2,5 mm², 24 -
12 AWG – –
2 core with the
same cross sec-
tion, flexible with
crimp connectors,
no plastic sleeve
0,25 - 1 mm², 24 -
16 AWG
0,25 - 1 mm², 24 -
16 AWG – –
2 core with the
same cross sec-
tion, flexible
without crimp
connectors or
with TWIN crimp
connectors
0,2 - 1,5 mm², 24 -
16 AWG
0,2 - 1,5 mm², 24 -
16 AWG – –
Torque setting with
screw terminals 0,5 Nm 0,5 Nm – –
Stripping length with
screw terminals 8 mm 8 mm – –
Conductor cross
section with spring-
loaded terminals:
Flexible with/without
crimp connector – –
0,2 - 2,5 mm², 24 -
12 AWG
0,2 - 2,5 mm², 24 -
12 AWG
Spring-loaded ter-
minals: Terminal
points per connec-
tion – – 2 2
Stripping length with
spring-loaded ter-
minals – – 9 mm 9 mm
Dimensions
Height 98 mm 98 mm 100 mm 100 mm
Width 22,5 mm 22,5 mm 22,5 mm 22,5 mm
Depth 120 mm 120 mm 120 mm 120 mm
Weight 190 g 210 g 185 g 210 g
Where standards are undated, the 2022-09 latest editions shall apply.
