PNOZ s9
Operating Manual PNOZ s9
21401-EN-10
18
INFORMATION
Status indicators and error indicators may occur independently. In the case
of an error display, the "Fault" LED will light or flash (exception: "Supply
voltage too low"). An LED that is also flashing indicates the potential cause
of the error. An LED that is lit and is static indicates a normal operating
status. Several status indicators and error indicators may occur simultan-
eously.
Status indicators
POWER
Supply voltage is present.
IN1
Input circuit at S32 is closed.
IN2
Input circuit at S32 is closed.
OUT
Safety contacts are closed.
RESET
24 VDC is present at S34.
OUT
Set delay time is running.
Fault indicators
FAULT
Diagnostics: Plug terminator not connected
} Remedy: Insert plug terminator, switch supply voltage off and then on
again.
With base unit PNOZsigma:
Diagnostics: Input circuit S32 is closed without authorisation
FAULT
Diagnostics: Internal error, unit defective
} Remedy: Switch supply voltage off and then on again, change unit if neces-
sary.
