PNOZ s9
Operating Manual PNOZ s9
21401-EN-10
15
Set operating modes
} Switch off supply voltage.
} Select operating mode via the operating mode selector switch "mode".
} If the operating mode selector switch "mode" is in its start position (vertical position), an
error message will appear.
operating mode
selector switch
"mode"
delay-on de-en-
ergisation, not
retriggerable
delay-on de-en-
ergisation,
retriggerable
delay-on ener-
gisation
pulse on switch-
ing on
Set delay time
Time selector switch "t[s]"
Factor selector switch "n"
n x t[s] = Delay time
Example:
t = 4 s, n = 5
Delay time = 5 x 4 = 20 s
Connection
} Supply voltage
Supply voltage AC DC
INFORMATION
The supply voltage may only be connected as shown in the examples listed
below!
