Pilz PNOZ X2.5P Series User Manual

PNOZ X2.5P
Operating Manual PNOZ X2.5P
20407-EN-10
15
Inputs 777308 787308
Max. overall cable resistance Rl-
max
Single-channel at UB DC 50 Ohm 50 Ohm
Dual-channel with detection of
shorts across contacts at UB DC
20 Ohm 20 Ohm
Semiconductor outputs 777308 787308
Number 1 1
Voltage 24 V 24 V
Current 100 mA 100 mA
External supply voltage 24 V 24 V
Voltage tolerance -20 %/+20 % -20 %/+20 %
Relay outputs 777308 787308
Number of output contacts
Safety contacts (N/O), instant-
aneous 2 2
Max. short circuit current IK 1 kA 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1 EN 60947-4-1
Utilisation category of safety con-
tacts
AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 6 A 6 A
Max. power 1500 VA 1500 VA
DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 6 A 6 A
Max. power 150 W 150 W
Utilisation category
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Utilisation category of safety con-
tacts
AC15 at 230 V 230 V
Max. current 5 A 5 A
DC13 (6 cycles/min) at 24 V 24 V
Max. current 4 A 4 A
Utilisation category in accordance
with UL
Voltage 240 V AC G. P. 240 V AC G. P.
With current 6 A 6 A
Voltage 24 V DC Resistive 24 V DC Resistive
With current 6 A 6 A
Pilot Duty B300, R300 B300, R300

Pilz PNOZ X2.5P Series Specifications

General

Brand	Pilz
Model	PNOZ X2.5P Series
Category	Relays
Language	English
