Pilz PNOZ X2.5P Series User Manual

PNOZ X2.5P
Operating Manual PNOZ X2.5P
20407-EN-10
16
Relay outputs 777308 787308
External contact fuse protection,
safety contacts
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Max. melting integral 100 A²s 100 A²s
Blow-out fuse, quick 6 A 6 A
Blow-out fuse, slow 4 A 4 A
Blow-out fuse, gG 6 A 6 A
Circuit breaker 24V AC/DC,
characteristic B/C 4 A 4 A
Conventional thermal current 6 A 6 A
Contact material AgSnO2 + 0,2 µm Au AgSnO2 + 0,2 µm Au
Times 777308 787308
Switch-on delay
With automatic start typ. 90 ms 90 ms
With automatic start max. 180 ms 180 ms
With automatic start after power
on typ. 90 ms 90 ms
With automatic start after power
on max. 180 ms 180 ms
With manual start typ. 35 ms 35 ms
With manual start max. 180 ms 180 ms
Delay-on de-energisation
With E-STOP typ. 15 ms 15 ms
With E-STOP max. 30 ms 30 ms
With power failure typ. 60 ms 60 ms
With power failure max. 90 ms 90 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 50 ms 50 ms
After power failure 150 ms 150 ms
Supply interruption before de-ener-
gisation
20 ms 20 ms
Simultaneity, channel 1 and 2 max. ∞ ∞
Environmental data 777308 787308
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during operation Not permitted Not permitted
EMC EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
