Pilz PNOZ X2 User Manual

PNOZ X2
Operating Manual PNOZ X2
1003353-EN-08
| 10
Preparing for operation
Supply voltage AC DC
A1
A2
L1
N
A1
A2
L+
L-
Input circuit Single-channel Dual-channel (with detection of
shorts across contacts)
E-STOP
S1
S22
S21
S12
S11
L+A1
S1
S22
S21
S12
S11
Safety gate
S1
S22
S21
S12
S11
L+A1
S1
S2
S12
S11
S22
S21
NOTICE
With single-channel wiring the safety level of your machine/plant may be
lower than the safety level of the unit (see Safety characteristic
data [ 16]).
Start circuit E-STOP wiring (single-channel),
safety gate (single-channel)
E-STOP wiring (dual-channel),
safety gate (dual-channel)
Monitored start
Feedback loop Single-channel Dual-channel
Contacts from external contactors

Pilz PNOZ X2 Specifications

General

Category	Safety Relay
Width	22.5 mm
Height	87 mm
Depth	121 mm
Mounting	DIN Rail
Rated Current per Channel	6 A
Supply Voltage	24 V DC
Contacts	2 N/O
Stop Category	0
Weight	200 g
Standards	EN 60204-1
