Page #13 background imageLoading...
Page #13 background image
PNOZ X2
Operating Manual PNOZ X2
1003353-EN-08
| 13
Technical details
General
Certifications CCC, CE, EAC (Eurasian), TÜV, cULus Listed
Electrical data
Supply voltage
Voltage 24 V
Kind AC/DC
Voltage tolerance -15 %/+10 %
Output of external power supply (AC) 4,5 VA
Output of external power supply (DC) 2 W
Frequency range AC 50 - 60 Hz
Residual ripple DC 160 %
Duty cycle 100 %
Max. inrush current impulse
Current pulse, A1 1,7 A
Pulse duration, A1 1,5 ms
Inputs
Number 2
Voltage at
Input circuit DC 24 V
Start circuit DC 24 V
Feedback loop DC 24 V
Current at
Input circuit DC 25 mA
Start circuit DC 30 mA
Feedback loop DC 30 mA
Min. input resistance at power-on 468 Ohm
Max. overall cable resistance Rlmax
Single-channel at UB DC 50 Ohm
Single-channel at UB AC 150 Ohm
Dual-channel with detection of shorts across con-
tacts at UB DC 15 Ohm
Dual-channel with detection of shorts across con-
tacts at UB AC 30 Ohm
Relay outputs
Number of output contacts
Safety contacts (N/O), instantaneous 2
Max. short circuit current IK 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1
