Operating Manual PNOZ X9P
1003362-EN-12
| 21
Conventional thermal current
while loading several contacts
777606 787606
Ith per contact at UB AC;
AC1:240V,DC1:24V
Conv. therm. current with 1 con-
tact 8 A 8 A
Conv. therm. current with 2 con-
tacts 8 A 8 A
Conv. therm. current with 3 con-
tacts 8 A 8 A
Conv. therm. current with 4 con-
tacts 7 A 7 A
Conv. therm. current with 5 con-
tacts 6 A 6 A
Conv. therm. current with 6 con-
tacts 5,5 A 5,5 A
Conv. therm. current with 7 con-
tacts 5 A 5 A
Ith per contact at UB DC;
AC1:240V,DC1:24V
Conv. therm. current with 1 con-
tact 8 A 8 A
Conv. therm. current with 2 con-
tacts 8 A 8 A
Conv. therm. current with 3 con-
tacts 8 A 8 A
Conv. therm. current with 4 con-
tacts 7 A 7 A
Conv. therm. current with 5 con-
tacts 6 A 6 A
Conv. therm. current with 6 con-
tacts 5,5 A 5,5 A
Conv. therm. current with 7 con-
tacts 5 A 5 A
Times 777606 787606
Switch-on delay
With automatic start typ. 200 ms 200 ms
With automatic start max. 250 ms 250 ms
With automatic start after power
on typ. 500 ms 500 ms
With automatic start after power
on max. 650 ms 650 ms
With manual start typ. 200 ms 200 ms
With manual start max. 250 ms 250 ms
With monitored start typ. 150 ms 150 ms
With monitored start max. 220 ms 220 ms
