Pilz PNOZ X9P User Manual

PNOZ X9P
Operating Manual PNOZ X9P
1003362-EN-12
| 22
Times 777606 787606
Delay-on de-energisation
With E-STOP typ. 20 ms 20 ms
With 24 V power failure at A1
typ. 230 ms 230 ms
With E-STOP max. 30 ms 30 ms
With power failure at B1 typ. 170 ms 170 ms
With power failure at B1 max. 250 ms 250 ms
With 240 V power failure at A1
max. 550 ms 550 ms
With 240 V power failure at A1
typ. 430 ms 430 ms
With 24 V power failure at A1
max. 300 ms 300 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 50 ms 50 ms
After power failure at A1 600 ms 600 ms
Min. start pulse duration with a
monitored start 50 ms 50 ms
Supply interruption before de-ener-
gisation 20 ms 20 ms
Environmental data 777606 787606
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during operation Not permitted Not permitted
EMC EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
Vibration
In accordance with the standard EN 60068-2-6 EN 60068-2-6
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 0,35 mm 0,35 mm
Airgap creepage
In accordance with the standard EN 60947-1 EN 60947-1
Overvoltage category III / II III / II
Pollution degree 2 2
Rated insulation voltage 250 V 250 V
Rated impulse withstand voltage 4 kV 4 kV
Protection type
Housing IP40 IP40
Terminals IP20 IP20
Mounting area (e.g. control cab-
inet) IP54 IP54
