PNOZ XV1P
Operating Manual PNOZ XV1P
20596-EN-07
16
Technical details
Order no. 777601 – 777602
See below for more order numbers
General 777601 777602
Approvals
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
Electrical data 777601 777602
Supply voltage
Voltage 24 V 24 V
Kind DC DC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(DC) 3,5 W 3,5 W
Residual ripple DC 20 % 20 %
Duty cycle 100 % 100 %
Max. inrush current impulse
Current pulse, A1 5 A 5 A
Pulse duration, A1 1 ms 1 ms
Inputs 777601 777602
Number 2 2
Voltage at
Input circuit DC 24 V 24 V
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
Current at
Input circuit DC 35 mA 35 mA
Start circuit DC 35 mA 35 mA
Feedback loop DC 3,5 mA 3,5 mA
Max. overall cable resistance Rl-
max
Single-channel at UB DC 100 Ohm 100 Ohm
Dual-channel without detection
of shorts across contacts at UB
DC 150 Ohm 150 Ohm
Dual-channel with detection of
shorts across contacts at UB DC 15 Ohm 15 Ohm
Relay outputs 777601 777602
Number of output contacts
Safety contacts (N/O), instant-
aneous 2 2
Safety contacts (N/O), delayed 1 1
Max. short circuit current IK 1 kA 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1 EN 60947-4-1
