Pilz PNOZ XV1P User Manual

PNOZ XV1P
Operating Manual PNOZ XV1P
20596-EN-07
17
Relay outputs 777601 777602
Utilisation category of safety con-
tacts
AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 5 A 5 A
Max. power 1250 VA 1250 VA
DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 5 A 5 A
Max. power 125 W 125 W
Utilisation category of safety con-
tacts delayed
AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 5 A 5 A
Max. power 1250 VA 1250 VA
DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 5 A 5 A
Max. power 125 W 125 W
Utilisation category
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Utilisation category of safety con-
tacts
AC15 at 230 V 230 V
Max. current 1,5 A 1,5 A
DC13 (6 cycles/min) at 24 V 24 V
Max. current 2 A 2 A
Utilisation category of safety con-
tacts delayed
AC15 at 230 V 230 V
Max. current 2 A 2 A
DC13 (6 cycles/min) at 24 V 24 V
Max. current 4 A 4 A
Utilisation category in accordance
with UL
Voltage 240 V AC G. P. 240 V AC G. P.
With current 5 A 5 A
Pilot Duty C300, R300 C300, R300
