Pilz PNOZ XV1P User Manual

PNOZ XV1P
Operating Manual PNOZ XV1P
20596-EN-07
18
Relay outputs 777601 777602
External contact fuse protection,
safety contacts
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Max. melting integral 66 A²s 66 A²s
Blow-out fuse, quick 6 A 6 A
Blow-out fuse, slow 4 A 4 A
Blow-out fuse, gG 6 A 6 A
Circuit breaker 24V AC/DC,
characteristic B/C 4 A 4 A
External contact fuse protection,
delayed safety contacts
Max. melting integral 66 A²s 66 A²s
Blow-out fuse, quick 6 A 6 A
Blow-out fuse, slow 4 A 4 A
Blow-out fuse, gG 6 A 6 A
Circuit breaker 24 V AC/DC,
characteristic B/C 4 A 4 A
Contact material AgSnO2 + 0,2 µm Au AgSnO2 + 0,2 µm Au
Conventional thermal current
while loading several contacts
777601 777602
Ith per contact at UB DC;
AC1:240V,DC1:24V
Conv. therm. current with 1 con-
tact 5 A 5 A
Conv. therm. current with 2 con-
tacts 3,7 A 3,7 A
Conv. therm. current with 3 con-
tacts 3 A 3 A
Times 777601 777602
Switch-on delay
With automatic start typ. 300 ms 300 ms
With automatic start max. 550 ms 550 ms
With automatic start after power
on typ. 350 ms 350 ms
With automatic start after power
on max. 750 ms 750 ms
With monitored start typ. 30 ms 30 ms
With monitored start max. 60 ms 60 ms
Delay-on de-energisation
With E-STOP typ. 15 ms 15 ms
With E-STOP max. 30 ms 30 ms
With power failure typ. 100 ms 100 ms
With power failure max. 150 ms 150 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 50 ms +tv 50 ms +tv
After power failure 300 ms 300 ms
– 0,1 - 3 s 1 - 30 s
