PNOZ XV1P
Operating Manual PNOZ XV1P
20596-EN-07
20
Mechanical data 777601 777602
Conductor cross section with screw
terminals
1 core flexible 0,25 - 2,5 mm², 24 - 12 AWG 0,25 - 2,5 mm², 24 - 12 AWG
2 core with the same cross sec-
tion, flexible with crimp connect-
ors, no plastic sleeve 0,25 - 1 mm², 24 - 16 AWG 0,25 - 1 mm², 24 - 16 AWG
2 core with the same cross sec-
tion, flexible without crimp con-
nectors or with TWIN crimp con-
nectors 0,2 - 1,5 mm², 24 - 16 AWG 0,2 - 1,5 mm², 24 - 16 AWG
Torque setting with screw terminals 0,5 Nm 0,5 Nm
Dimensions
Height 94 mm 94 mm
Width 22,5 mm 22,5 mm
Depth 121 mm 121 mm
Weight 230 g 230 g
Where standards are undated, the 2014-07 latest editions shall apply.
Order no. 787601 – 787602
General 787601 787602
Approvals
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
Electrical data 787601 787602
Supply voltage
Voltage 24 V 24 V
Kind DC DC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(DC) 3,5 W 3,5 W
Residual ripple DC 20 % 20 %
Duty cycle 100 % 100 %
Max. inrush current impulse
Current pulse, A1 5 A 5 A
Pulse duration, A1 1 ms 1 ms
Inputs 787601 787602
Number 2 2
Voltage at
Input circuit DC 24 V 24 V
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
