Pilz PNOZ XV1P User Manual

PNOZ XV1P
Operating Manual PNOZ XV1P
20596-EN-07
21
Inputs 787601 787602
Current at
Input circuit DC 35 mA 35 mA
Start circuit DC 35 mA 35 mA
Feedback loop DC 3,5 mA 3,5 mA
Max. overall cable resistance Rl-
max
Single-channel at UB DC 100 Ohm 100 Ohm
Dual-channel without detection
of shorts across contacts at UB
DC 150 Ohm 150 Ohm
Dual-channel with detection of
shorts across contacts at UB DC 15 Ohm 15 Ohm
Relay outputs 787601 787602
Number of output contacts
Safety contacts (N/O), instant-
aneous 2 2
Safety contacts (N/O), delayed 1 1
Max. short circuit current IK 1 kA 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1 EN 60947-4-1
Utilisation category of safety con-
tacts
AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 5 A 5 A
Max. power 1250 VA 1250 VA
DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 5 A 5 A
Max. power 125 W 125 W
Utilisation category of safety con-
tacts delayed
AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 5 A 5 A
Max. power 1250 VA 1250 VA
DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 5 A 5 A
Max. power 125 W 125 W
Utilisation category
In accordance with the standard EN 60947-5-1 EN 60947-5-1
