Pilz PNOZ XV1P User Manual

PNOZ XV1P
Operating Manual PNOZ XV1P
20596-EN-07
22
Relay outputs 787601 787602
Utilisation category of safety con-
tacts
AC15 at 230 V 230 V
Max. current 1,5 A 1,5 A
DC13 (6 cycles/min) at 24 V 24 V
Max. current 2 A 2 A
Utilisation category of safety con-
tacts delayed
AC15 at 230 V 230 V
Max. current 2 A 2 A
DC13 (6 cycles/min) at 24 V 24 V
Max. current 4 A 4 A
Utilisation category in accordance
with UL
Voltage 240 V AC G. P. 240 V AC G. P.
With current 5 A 5 A
Pilot Duty C300, R300 C300, R300
External contact fuse protection,
safety contacts
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Max. melting integral 66 A²s 66 A²s
Blow-out fuse, quick 6 A 6 A
Blow-out fuse, slow 4 A 4 A
Blow-out fuse, gG 6 A 6 A
Circuit breaker 24V AC/DC,
characteristic B/C 4 A 4 A
External contact fuse protection,
delayed safety contacts
Max. melting integral 66 A²s 66 A²s
Blow-out fuse, quick 6 A 6 A
Blow-out fuse, slow 4 A 4 A
Blow-out fuse, gG 6 A 6 A
Circuit breaker 24 V AC/DC,
characteristic B/C 4 A 4 A
Contact material AgSnO2 + 0,2 µm Au AgSnO2 + 0,2 µm Au
Conventional thermal current
while loading several contacts
787601 787602
Ith per contact at UB DC;
AC1:240V,DC1:24V
Conv. therm. current with 1 con-
tact 5 A 5 A
Conv. therm. current with 2 con-
tacts 3,7 A 3,7 A
Conv. therm. current with 3 con-
tacts 3 A 3 A
