Operating Manual PSEN sl-0.5n 1.1
22173-EN-05
24
Electrical data
Supply voltage
Voltage 24 V
Kind DC
Voltage tolerance -15 %/+10 %
Output of external power supply (DC) 4,8 W
Max. inrush current at UB 0,6 A
Max. switching frequency 1 Hz
Max. cable capacitance at the safety outputs
No-load, PNOZ with relay contacts 40 nF
PNOZmulti, PNOZelog, PSS 70 nF
No-load current 40 mA
Semiconductor outputs
OSSD safety outputs 2
Switching current per output 500 mA
Breaking capacity per output 12 W
Short circuit-proof yes
Residual current at outputs 250 µA
Voltage drop at OSSDs 1,5 V
Conditional rated short circuit current 100 A
Lowest operating current 0 mA
Utilisation category in accordance with EN 60947-1 DC-12
Times
Test pulse duration, safety outputs 450 µs
Switch-on delay
after UB is applied 1,6 s
Actuator typ. 500 ms
Delay-on de-energisation
Actuator typ. 40 ms
Actuator max. 260 ms
Risk time in accordance with EN 60947-5-3 260 ms
Supply interruption before de-energisation 15 ms
Environmental data
Temperature of metal surface at ambient temperat-
ure: 25 °C 60 °C
Ambient temperature
In accordance with the standard EN 60068-2-14
Temperature range -25 - 55 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2
Temperature range -25 - 70 °C
Climatic suitability
In accordance with the standard EN 60068-2-78
Humidity 93 % r. h. at 40 °C
EMC EN 55011: class A, EN 60947-5-3, EN 62061
