Operating Manual PSEN sl-0.5n 1.1
22173-EN-05
27
Technical Details Order No. 570563
General
Approvals CE, EAC (Eurasian), FCC, IC, TÜV, cULus Listed
Sensor's mode of operation Transponder
Coding level in accordance with EN ISO 14119 Low
Design in accordance with EN ISO 14119 4
Classification in accordance with EN 60947-5-3 PDDB
Pilz coding type Coded
Transponder
Frequency band 122 kHz - 128 kHz
Max. transmitter output 15 mW
Electrical data
Supply voltage
Voltage 24 V
Kind DC
Voltage tolerance -15 %/+10 %
Output of external power supply (DC) 4,8 W
Max. inrush current at UB 0,6 A
Max. switching frequency 1 Hz
Max. cable capacitance at the safety outputs
No-load, PNOZ with relay contacts 40 nF
PNOZmulti, PNOZelog, PSS 70 nF
No-load current 40 mA
Semiconductor outputs
OSSD safety outputs 2
Switching current per output 500 mA
Breaking capacity per output 12 W
Short circuit-proof yes
Residual current at outputs 250 µA
Voltage drop at OSSDs 1,5 V
Conditional rated short circuit current 100 A
Lowest operating current 0 mA
Utilisation category in accordance with EN 60947-1 DC-12
Times
Test pulse duration, safety outputs 450 µs
Switch-on delay
after UB is applied 1,6 s
Actuator typ. 500 ms
Delay-on de-energisation
Actuator typ. 40 ms
Actuator max. 260 ms
Risk time in accordance with EN 60947-5-3 260 ms
Supply interruption before de-energisation 15 ms
