PSEN sl-0.5n 1.1
Operating Manual PSEN sl-0.5n 1.1
22173-EN-05
26
Mechanical data
Dimensions
Height 122 mm
Width 45 mm
Depth 44 mm
Actuator dimensions
Height 138 mm
Width 52 mm
Depth 23 mm
Weight of safety switch 570 g
Weight of actuator 375 g
Weight 950 g
Where standards are undated, the 2015-04 latest editions shall apply.
