Pilz PSEN sl-0.5n 1.1 User Manual

PSEN sl-0.5n 1.1
Operating Manual PSEN sl-0.5n 1.1
22173-EN-05
25
Environmental data
Vibration
In accordance with the standard EN 60947-5-2
Frequency 10 - 55 Hz
Amplitude 1 mm
Shock stress
In accordance with the standard EN 60068-2-27
Number of shocks 3
Acceleration 30g
Duration 11 ms
In accordance with the standard EN 60068-2-27
Number of shocks 500
Acceleration 10g
Duration 16 ms
Airgap creepage
Overvoltage category III
Pollution degree 3
Rated insulation voltage 75 V
Rated impulse withstand voltage 1 kV
Protection type
Housing IP67
Mechanical data
Holding force FZh in accordance with ISO 14119 500 N
Magnetic holding force on 500 N
Magnetic holding force off 30 N
Max. vertical offset 5 mm
Max. lateral offset 3 mm
Max. angular offset 2,5 deg
Actuator 1 PSEN sl-0.5 1.1
Operating distances
Assured operating distance Sao 1 mm
Typical operating distance So 7 mm
Assured release distance Sar 15 mm
Repetition accuracy switching distances 40 %
Typ. Hysteresis 3 mm
Min. distance between safety switches 30 mm
Sensor flush installation in accordance with EN
60947-5-2 Yes, follow installation guidelines
Connection type M12, 5-pin male connector
Cable LiYY 5 x 0.25 mm2
Material
Top PBT
Anchor plate Nickel-plated steel
Base plate Anticorodal, hard anodised
Actuator Anticorodal, hard anodised
Max. torque setting for fixing screws 3 Nm
