Pinion Smart.Shift - System Overview

28
SYSTEM OVERVIEW
1
2
3
4
5
6
7
Fig.1
1
Smart.Shift gearbox (e.g. C1.12i)
2
Smart.Shift box
3
Cable outlet on the Smart.Shift box
4
E-trigger TE1
5
Pinion crank with sensor magnet
6
Wiring harness
7
Smart.Shift app
Optional equipment (not shown)
● Rechargeable battery (with charging extension cable if
necessary)
● Speed sensor with magnet on rear wheel
The components on your bike may deviate from this standard.
