Pinion Smart.Shift - Individual Components

29
INDIVIDUAL COMPONENTS
SMART.SHIFT GEARBOX
Fig.2
For the use of Pinion Smart.Shift technology, special variants of
Pinion gearboxes are required. Shifting mechanisms and sensor
technology are the main differences. All gearboxes compatible
with Smart.Shift are marked with “i” on the series label
(C1.12
i
, C1.9
i
, C1.6
i
).
SMART.SHIFT BOX
1
2
3
Fig.3
1
Integrated LED
2
Waterproof cable outlet
3
Serial number on back
