Pioneer DEH-P310 - Eq-Low;MID;High; Equalizer Curve Fine Adjustment

29
Audio Adjustment
Equalizer Curve Fine Adjustment
You can adjust the center frequency and the Q factor (curve characteristics) of each cur-
rently selected curve band (EQ-LOW/MID/HIGH). Adjusted equalizer curve settings are
memorized in “CUSTOM”.
1. Press the AUDIO button for 2 or more seconds to select Equalizer Curve
Fine Adjustment.
Note:
• If you make adjustments when a curve other than “CUSTOM” is selected, the newly adjusted curve
will replace the previous adjusted curve. Then a new curve with “CUSTOM” appears on the display
while selecting the equalizer curve. (Refer to page 27.)
4. Select the desired Q factor with
the 5/∞ buttons.
2N Ô 1N Ô 1W Ô 2W
3. Select the desired frequency
with the 2/3 buttons.
LOW: 40 Ô 80 Ô 100 Ô 160 (Hz)
MID: 200
Ô 500 Ô 1K Ô 2K (Hz)
HIGH: 3K
Ô 8K Ô 10K Ô 12K (Hz)
2. Press the AUDIO button to
select the desired band for
adjustment.
Level (dB)
Q=2W
Q=2N
Center frequency
Frequency (Hz)
