PDP-433PU
105
5 678
56
7
8
C
D
F
A
B
E
Pin Assignment (Top View)
Pin Function
Block Diagram
PST9246N (DIGITAL VIDEO ASSY: IC1208)
Drive Protect PLD
54
VCC VOUT
321
GNDSUBTC
SOT-25
(TOP VIEW)
Pin No. Pin name Functions
1TC
SUB
TPLH control pin
Substate pin
2
3 GND GND pin
4V
OUT Reset signal output pin
5V
CC VCC pin / voltage detect pin
