PDP-502MX, PDP-502MXE
38
39 *YLW Yellow LED lighting Low: In lighting Yellow LED O
40 *V_STD Not used
41 IP_BUSY BUSY signal from IP u-com High: At the timing of H SYNC I
42 IP_ERR
Communication error signal from IP u-com
Low: Normal I
43 HOLD_SU
Command to hold detected frequency value
Low: Normal O
to SYNC u-com
44 V_MUTE Analog video mute output High: When muting, Low: Normal O
45
ZOOM_CLK
Not used
46
ZOOM_DATA
Not used
47
*PN_MUTEX
X Drive Panel mute output High: Normal, Low: When muting O
48
*PN_MUTEY
Y Drive Panel mute output Fixed "High" O
49 *V_STDO Not used
50 STDSW Not used
51 *PN_CE Chip Enable for Panel u-com & IP u-com High: Normal, Low: During communication O
52 *PLL_CE Chip Enable for PLL IC High: Normal, Low: During communication O
(Approx.80ms interval)
53 *OSD_CE Chip Enable for OSD IC High: Normal, Low: During communication O –– ––
54 *DAC_CE Chip Enable for DAC High: Normal, Low: During communication O
(Approx.20ms interval)
55 PGM_OE Not used
56 *PLD_CE Chip Enable for PLD (Analog Video Assy) High: Normal, Low: During communication O
(Approx.80ms interval)
57 *SU_CE Chip Enable for SYNC u-com High: Normal, Low: During communication O
58 *ZOOM_CE Chip Enable for Full Auto Zoom IC High: Normal, Low: During communication O –– ––
59 *A_MUTE1 Audio Mute 1 High: Normal, Low: When muting O ––
60 *A_MUTE2 Audio Mute 2 Muting audio out High: Normal, Low: When muting O ––
61 FAN_MAX Command to rotate Fan with max. speed High: In setting Fan max. speed, Low: Normal O
62 A_MUTE3 Audio Mute 3 Mute in suspending High: When muting, Low: Normal O ––
63 *OSD_CLR Reset signal output to OSD IC High: Normal, Low: In resetting O ––
64 OSD_H OSD Timing Pulse for SYNC processing Pulse input I –– ––
65 ––––– No allocation (Not used)
66 DRV_OFF Not used
67 *CB_MUTE Combination Mute High: When ID is set, Low: Normal O ––
68 REMSW Not used
69 PLK_ID Not used
70 ––––– No allocation (not used)
71 VCC Power source input STB +5V I
72 VREF Reference voltage input of AD/DA Converters STB +5V I
73 AVSS Analog power input of AD/DA Converters STBGND I
74 S_D Shut down detection for high temperature High: In high temperature, Low: Normal I
75 TEMP2 Not used
76 TEMP
Temperature detection for On screen bar display
0–5V DC value I
77 ––––– No allocation (Not used)
78 ––––– No allocation (Not used)
79 ––––– No allocation (Not used)
80 PM_ST Not used
