Pioneer PDP-502MX Service Manual

PDP-502MX, PDP-502MXE
45
Mark No. Description Part No.
Mark No. Description Part No.
C1445, C1449–C1451, C1482, C149 CKSRYF104Z16
C1493, C1495, C1497, C1499, C1502 CKSRYF104Z16
C1506, C1508, C1723, C1725, C1727 CKSRYF104Z16
C1729, C1731, C1733, C1735 CKSRYF104Z16
C1758, C1759, C1776, C1782, C1790 CKSRYF104Z16
C1792, C1794, C1795, C1800–C1803 CKSRYF104Z16
C1811–C1813, C2006, C2008, C2025 CKSRYF104Z16
C2034, C2053, C2058, C2060–C2063 CKSRYF104Z16
C2065–C2067, C2069, C2070, C2073 CKSRYF104Z16
C2079, C2202–C2204, C2211 CKSRYF104Z16
C2214, C2215, C2217, C2301, C2302 CKSRYF104Z16
C2401–C2405, C2407–C2413 CKSRYF104Z16
C2415–C2418, C2420–C2424 CKSRYF104Z16
C2426–C2432, C2434–C2438 CKSRYF104Z16
C2440–C2446, C2454–C2456 CKSRYF104Z16
C2458, C2459, C2462, C2465, C2472 CKSRYF104Z16
C2475, C2478–C2480, C2482, C2484 CKSRYF104Z16
C2486, C2488, C2490, C2492, C2494 CKSRYF104Z16
C2704–C2708, C2710–C2714, C2717 CKSRYF104Z16
C2720, C2723, C2725, C2730 CKSRYF104Z16
C2903–C2909, C2937, C2939, C309 CKSRYF104Z16
C314, C315, C323, C328 CKSRYF104Z16
C336, C337, C3401–C3406, C341 CKSRYF104Z16
C3412, C3414, C3416, C3418 CKSRYF104Z16
C3420, C3421, C343, C3430, C3431 CKSRYF104Z16
C3433, C3434, C353, C366–C374 CKSRYF104Z16
C376, C377, C379, C505, C507 CKSRYF104Z16
C513, C515, C525, C527, C530 CKSRYF104Z16
C534, C536, C539, C540, C542 CKSRYF104Z16
C544–C547, C657–C660 CKSRYF104Z16
RESISTORS
R2901–R2912 (47 Ω) DCN1090
R2153–R2158, R2452–R2463 (100 Ω) DCN1092
R2226–R2231 (10 kΩ) DCN1094
R3115–R3126 (22 Ω) DCN1104
R2413, R2415 RN1/10SE1001D
R2412 RN1/10SE1501D
R2722 RN1/10SE1601D
R2414 RN1/10SE2001D
R2721 RN1/10SE3301D
R2485, R2948, R3402, R3404, R3407 RS1/10S1001F
R306, R317, R507, R519 RS1/10S1002F
R1768 RS1/10S1102F
R1225, R2079 RS1/10S1502F
R1808 RS1/10S1602F
R1776 RS1/10S1802F
R1817 RS1/10S2201F
R1227, R1409 RS1/10S2202F
R3403 RS1/10S2401F
R2486 RS1/10S3001F
R310, R321, R511, R542 RS1/10S3301F
R2086 RS1/10S3302F
R1811, R1815, R1820 RS1/10S3601F
R3401, R3410 RS1/10S3900F
R1818 RS1/10S3901F
R1812–R1814, R1816, R1819 RS1/10S4701F
R1821, R1822, R307, R318, R508 RS1/10S4701F
R520 RS1/10S4701F
R1402 RS1/10S4702F
R2085 RS1/10S4703F
R3412 RS1/10S5600F
R309, R510 RS1/10S5601F
R3411 RS1/10S6200F
R320, R3405, R3408, R544 RS1/10S6201F
R1848 RS1/10S6801F
R2949, R2950 RS1/10S8200F
R2148, R2150, R2163, R2168, R2710 RS1/16S0R0J
R2717, R2725, R2913, R2914 RS1/16S0R0J
R2919–R2927, R2936–R2941, R3423 RS1/16S0R0J
R2709, R2713–R2716, R2928–R2930 RS1/16S100J
R2932 RS1/16S100J
R2033, R2041–R2045, R2089–R2091 RS1/16S101J
R2095, R2096, R2099–R2109 RS1/16S101J
R2111–R2113, R2118–R2122, R2127 RS1/16S101J
R2237–R2239, R2241–R2252 RS1/16S101J
R2254–R2261, R2273–R2281, R2446 RS1/16S101J
R2448, R2450, R2494–R2496, R2915 RS1/16S101J
R2706, R2740 RS1/16S102J
R2087, R2088, R2139–R2141 RS1/16S103J
R2159, R2160, R2164–R2167, R2170 RS1/16S103J
R2236, R2253, R2293–R2298, R2332 RS1/16S103J
R2339–R2342, R2348, R2349, R2447 RS1/16S103J
R2449, R2451, R3131, R3139–R3141 RS1/16S103J
R2488, R2490, R2492 RS1/16S152J
R2744 RS1/16S2201D
R2701–R2703, R2705, R2720, R2723 RS1/16S220J
R2742 RS1/16S220J
R2162 RS1/16S221J
R2743 RS1/16S2701D
R2489, R2491, R2493 RS1/16S302J
R2429, R2430, R2433, R2434 RS1/16S331J
R2741, R3418, R3424 RS1/16S332J
R2931, R2933, R2934 RS1/16S470J
R2918, R3130 RS1/16S472J
R2724 RS1/16S473J
R2497, R3413 RS3LMF1R5J
R3420, R3421 RS3LMF4R7J
R3422 RS3LMFR47J
Other Resistors RS1/10S J
OTHERS
CN2901, CN2902 30P CONNECTER 20143–030E–01
652 PIN JACK (2P) AKB1099
CN103, CN1402 PLUG 6–P AKM1163
CN3408 TAB 1P AKM1177
CN104, CN1203 PLUG 12–P AKM1178
