PDP-502MX, PDP-502MXE
46
Mark No. Description Part No.
Mark No. Description Part No.
CN651 JACK AKN1069
CN102 SIN SOCKET AKP1175
CN501, CN502 15P D–SUB SOCKET AKP1195
101 CONNECTOR AKX1053
K1404, K1701–K1703, K2004, K2005 AKX9002
K2012–K2033, K2201–K2213 AKX9002
K2404–K2419, K2701–K2716 AKX9002
K2901–K2906 AKX9002
X2001 (16.0 MHz) ASS1145
X1201 (16.2 MHz) ASS1152
CN2202 CONNECTOR B10B–PH–SM3
CN2203 CONNECTOR B11B–PH–SM3
CN2001, CN3401 CONNECTOR B12B–PH–SM3
CN2903, CN302 CONNECTOR B6B–PH–SM3
CN2002 CONNECTOR B7B–PH–SM3
CN3404 CONNECTOR B8B–PH–SM3
CN3406, CN3407 CONNECTOR B9B–PH–SM3
3406, 3407 SCREW BMZ30P060FCU
VIDEO ASSY (AWZ6448: PDP-502MXE)
SEMICONDUCTORS
IC104 24LC64(I)SN
IC507 24LCS21A
IC1702, IC306 BA7657F
IC2301, IC2302 CXA1875AM
IC1401 CXA2101AQ
IC2701 CXA3106Q
IC2401 –IC2403 CXA3256R
IC2404 KIA431F
IC506 LT1260CS
IC1701 M52337SP
IC2002 M52346SP
IC1704 M62358FP
IC1705 NJM072BM-E
IC307 NJM2234M
IC301, IC303, IC501, IC503 NJM360M
IC2201 PD2060A9
IC2005 PE9006C
IC2704, IC3401 –IC3403 PQ05TZ51
IC2405, IC2901, IC3405, IC3406 PQ20VZ1U
IC3404 PQ30RV21
IC2203 PST9146N
IC3408 TA79L05F
IC651 TC4052BF
IC1404 TC74HC4053AF
IC2902 –IC2908 TC74LCX541FT
IC2004 TC74VHC123AFT
IC2003, IC2007, IC2202, IC305 TC74VHCT541AFT
IC2204, IC502, IC504 TC7SET08FU
IC2702, IC2703 TC7SH04FU
IC2205 TC7W08FU
IC2006 TC7WU04FU
Q1401 –Q1403, Q1418, Q1419 2SA1037K
Q1427, Q1428, Q1433, Q1435, Q1438 2SA1037K
Q1701 –Q1703, Q1714, Q1718 –Q1720 2SA1037K
Q1724 –Q1729, Q2004, Q2008, Q2406 2SA1037K
Q2408, Q2412, Q2414, Q2416, Q2418 2SA1037K
Q2701, Q306, Q308 –Q310 2SA1037K
Q1404, Q1431, Q1432, Q1436 2SC2412K
Q1439 –Q1442, Q1444, Q1445 2SC2412K
Q1704 –Q1713, Q1721 –Q1723, Q1731 2SC2412K
Q2001, Q2003, Q2401 –Q2405, Q2407 2SC2412K
Q2409 –Q2411, Q2413, Q2415, Q2417 2SC2412K
Q2703, Q302, Q304, Q502, Q504 2SC2412K
Q507 –Q509, Q651, Q652 2SC2412K
Q2009 DTA124EK
Q1420, Q1429, Q1434, Q1443, Q1730 DTC124EK
Q2005, Q2007, Q2702 DTC124EK
Q301, Q303, Q312 –Q314 UMY1N
Q316 –Q318, Q501, Q503 UMY1N
Q505, Q506 UMY1N
D1402, D1705 –D1710, D512 1SS184
D106, D107, D301 –D305, D307 1SS226
D309, D311 –D313, D315 –D317 1SS226
D450, D451, D502, D504 –D511 1SS226
D514 –D520, D651 –D654 1SS226
D1401, D1403, D1701 –D1704 1SS352
D2005 –D2010, D2201, D2701, D306 1SS352
D308, D501, D503 1SS352
D513 RD6.8MB
COILS AND FILTERS
F101, F1701, F2001 –F2003 ATF1189
F2401 –F2405, F2701, F2702 ATF1189
F3401 –F3403 ATF1189
L651 –L654 LCTA1R0J3225
L655, L656 LCTA2R2J3225
L301, L302, L501, L502 LCTA470J3225
SWITCHES AND RELAYS
S3401 ASH1047
CAPACITORS
C1752, C2719, C2722 (0.47 µF/16V) ACE1130
C2074, C2075 CCSQCH100D50
C2219, C2718 CCSQCH101J50
C1753 –C1755 CCSQCH121J50
C2031, C2032 CCSQCH151J50
C2077, C2078, C2208, C2209 CCSQCH220J50
C2701 –C2703 CCSQCH220J50
C1707, C1714, C1720, C2013, C2021 CCSQCH221J50
C2213 CCSQCH221J50
C1483, C1507 CCSQCH271J50
