Pioneer PDP-502MX Service Manual

PDP-502MX, PDP-502MXE
54
CAPACITORS
C3674 CCSRCH101J50
C3645, C3648, C3653, C3654 CCSRCH220J50
C3673 CCSRCH470J50
C3646, C3647 CCSRSL221J50
C3656, C3660, C3951, C3958 CEV100M16
C3962, C3963, C3967 CEV100M16
C3664, C3666, C3669, C3670 CEV100M35
C3617, C3618, C3628, C3634, C3638 CEV101M6R3
C3640, C3643, C3658, C3663 CEV101M6R3
C3613, C3659 CEV1R0M50
C3614 CEV220M16
C3610 CEV2R2M50
C3602, C3622, C3631, C3632, C3668 CEV470M16
C3672, C3953, C3955, C3956, C3959 CEV470M16
C3961, C3969, C3970 CEV470M16
C3612 CEVR47M50
C3603 CFHSP104J16
C3665, C3667, C3671, C3952, C3957 CKSQYB103K50
C3960, C3965 CKSQYB103K50
C3954, C3964 CKSQYB104K25
C3615, C3620, C3623–C3627, C3644 CKSRYB102K50
C3652 CKSRYB102K50
C3601, C3604–C3606, C3609, C3616 CKSRYB103K50
C3619, C3621, C3629, C3630, C3633 CKSRYB103K50
C3635, C3639, C3641, C3642, C3655 CKSRYB103K50
C3657, C3661, C3662 CKSRYB103K50
C3607, C3608, C3611, C3675 CKSRYB472K50
RESISTORS
R3971 RD1/2MMF100J
R3757 RD1/2MMF3R9J
R3872 RD1/4PU102J
R3951, R3957, R3958, R3960, R3975 RN1/10SE1001D
R3989, R4020, R4022–R4024 RN1/10SE1001D
R3953, R3984 RN1/10SE1801D
R3974 RN1/10SE3001D
R3959, R4021, R4038 RN1/10SE3601D
R3955, R3996 RN1/10SE3901D
R3967, R3985 RN1/10SE4701D
R3952, R3968 RN1/10SE5601D
R3973 RN1/10SE6201D
R3964, R3972, R3995, R3997, R4035 RN1/10SE6801D
R3801, R3885, R3890–R3904 RS1/16S0R0J
R3650, R3662, R3663, R3678–R3683 RS1/16S101J
R3737, R3753, R3765–R3767, R3780 RS1/16S101J
R3786, R3826, R3827, R3838, R3839 RS1/16S101J
R3842–R3845, R3853–R3862 RS1/16S101J
R3654, R3667, R3820–R3825 RS1/16S102J
R3830–R3837, R3850, R3863–R3868 RS1/16S102J
R3873–R3875 RS1/16S102J
R3634, R3635, R3651, R3652, R3661 RS1/16S103J
R3684, R3696–R3698, R3700–R3705 RS1/16S103J
R3725, R3726, R3738, R3740–R3749 RS1/16S103J
R3758, R3768, R3769, R3772 RS1/16S103J
R3774, R3775, R3777, R3785, R3791 RS1/16S103J
R3794, R3797–R3800, R3818, R3819 RS1/16S103J
R3852 RS1/16S103J
R3647 RS1/16S152J
R3658 RS1/16S153J
R3670–R3677, R3685–R3695, R3699 RS1/16S221J
R3706–R3724, R3727, R3728 RS1/16S221J
R3732–R3734, R3739, R3750–R3752 RS1/16S221J
R3754, R3755, R3770, R3773, R3790 RS1/16S221J
R3817, R3846, R3847 RS1/16S221J
R3610–R3625, R3664, R3665 RS1/16S222J
R3809, R3810, R3840, R3841 RS1/16S222J
R3636, R3657, R3778, R3851 RS1/16S223J
R3637, R3638 RS1/16S333J
R3656 RS1/16S392J
R3655, R3807, R3808 RS1/16S470J
R3648, R3781 RS1/16S471J
R3626–R3633, R3645, R3646 RS1/16S472J
R3659, R3660, R3666, R3668, R3669 RS1/16S472J
R3849 RS1/16S472J
R3653, R3729–R3731, R3771, R3779 RS1/16S473J
R3784, R3789, R3816, R3848 RS1/16S473J
R3870, R3871, R3884 RS1/16S473J
R3811–R3814 RS1/16S561J
R3649 RS1/16S562J
R3639–R3644, R3828, R3829 RS1/16S822J
R3792 RS1MMFR47J
R3759, R3760 RS2MMF150J
Other Resistors RS1/10S J
OTHERS
CN3617, CN3618 TAB 1P AKM1177
K3601–K3611, K3952, K3954, K3955 AKX9002
K3957 AKX9002
X3601 CRYSTAL RESONATOR ASS1127
X3602 ASS9005
CN3602, CN3605 CONNECTOR B10B–PH–SM3
CN3606, CN3612, CN3911 B11B–PH–SM3
CONNECTOR
CN3608 CONNECTOR B12B–PH–SM3
CN3912, CN3916, CN3917 B13B–PH–SM3
CONNECTOR
CN3921 B4PS–VH
CN3607, CN3920, CN3926, CN3929, B6B–PH–SM3
CN3953 CONNECTOR
CN3930 B6PS–VH
CN3914 CONNECTOR B7B–PH–SM3
CN3610 CONNECTOR B8B–PH–SM3
CN3913 8P–VH SIDE–CONNECTOR B8PS–VH
CN3603, CN3609, CN3611, CN3915 B9B–PH–SM3
CONNECTOR
SIDE SW ASSY
SEMICONDUCTORS
D3941 AEL1170
Mark No. Description Part No. Mark No. Description Part No.
