Pioneer PDP-502MX Service Manual

PDP-502MX, PDP-502MXE
55
SWITCHES AND RELAYS
S3941–S3951 ASG1034
RESISTORS
R3941 RS1/16S0R0J
OTHERS
CN3942 CONNECTOR B10B–PH–SM3
SENSOR A ASSY
SEMICONDUCTORS
IC4101 LM50CIM3
CAPACITORS
C4101 CKSRYB103K50
C4102 CKSRYF104Z16
RESISTORS
R4101 RS1/16S101J
OTHERS
CN4101 CONNECTOR B6B–PH–SM3
FAN CABLE A ASSY
CAPACITORS
C4251 CEV470M16
AUDIO ASSY
SEMICONDUCTORS
IC4502 LA4485
IC4501 TA7630P
Q4508 2SA1037K
Q4502, Q4504, Q4507, Q4510 2SC2412K
Q4512–Q4515 2SC2412K
Q4505, Q4506 DTC124EK
D4504 1SS181
D4508 1SS184
D4502, D4503, D4505–D4507, D4509 1SS226
D4501 1SS352
COILS AND FILTERS
L4501, L4502 ATH–059
L4503, L4504 (4.7 µH) ATH9003
CAPACITORS
C4509, C4510 CCSQCH221J50
C4517, C4539 CEAT101M16
C4535 CEAT221M16
C4534 CEAT471M16
C4520, C4522, C4546, C4550 CEAT471M25
C4526–C4529, C4531, C4533 CEV100M16
C4537, C4538, C4543, C4547 CEV100M16
C4532, C4536, C4544, C4545 CEV1R0M50
C4549 CEV220M35
C4524, C4525 CEV2R2M50
C4502, C4504 CFTXA154J50
C4518, C4542 CKSRYB392K50
C4501, C4503 CKSRYB562K50
C4505–C4508, C4511–C4513, C4516 CKSRYF103Z50
C4523, C4548 CKSRYF103Z50
C4540 CKSRYF223Z50
RESISTORS
R4537, R4540 RD1/2MMF152J
R4563 RD1/2MMF3R9J
R4522, R4529, R4534, R4554–R4556 RS1/16S101J
R4562, R4564–R4567, R4572 RS1/16S101J
R4506, R4568–R4571 RS1/16S102J
R4507, R4517, R4518, R4526, R4531 RS1/16S103J
R4548, R4549, R4558 RS1/16S103J
R4511, R4512 RS1/16S104J
R4519 RS1/16S122J
R4515, R4516 RS1/16S152J
R4513, R4514, R4527, R4559 RS1/16S182J
R4546 RS1/16S221J
R4505, R4532 RS1/16S222J
R4533, R4547 RS1/16S223J
R4543 RS1/16S224J
R4502, R4504, R4509, R4510, R4525 RS1/16S332J
R4550, R4557 RS1/16S332J
R4508, R4528, R4530, R4545 RS1/16S472J
R4560, R4561 RS1/16S472J
R4544 RS1/16S473J
R4541, R4542 RS1/16S683J
R4501, R4503 RS1/16S821J
OTHERS
4501 HEAT SINK ANH1559
CN4503 CONNECTOR B13B–PH–SM3
4502 SCREW BMZ30P060FZK
4501 DC–DC CONVERTER PP15–12–15
CONTROL ASSY
SEMICONDUCTORS
IC4701 UPC4570G2
Q5742, Q5746, Q5748 2SA1162
Q5741, Q5743–Q5745, Q5747 2SC2712
Q4701–Q4703 2SC4081
D5741–D5745 1SS352
D4701–D4704, D4706 1SS355
COILS AND FILTERS
F4701, F4702 ATF9017
L4701 ATH1073
L5741 LCTA221J3225
Mark No. Description Part No. Mark No. Description Part No.
