PDP-502MX, PDP-502MXE
58
R345 RS3LMF473J
VR111, VR356 VRTS6VS102
VR201 VRTS6VS104
VR401 VRTS6VS222
VR131 VRTS6VS224
VR301 VRTS6VS473
Other Resistors RS1/10S J
OTHERS
H101, H102 FUSE HOLDER AKR1007
K111–K113, K131, K132 AKX9002
K201, K202, K301, K302 AKX9002
K351–K356, K401, K404–K409 AKX9002
1 HEAT SINK S ANH1560
2 HEAT SINK L1 ANH1561
HEAT SINK L2 ANH1562
4 HEAT SINK L3 ANH1563
KN201 GROUND PLATE ANK–142
CN355 CONNECTOR B11B–PH–SM3
CN306 CONNECTOR B12B–PH–SM3
CN354 CONNECTOR B13B–PH–SM3
CN101, CN131 CONNECTOR B2P3–VH
CN353 CONNECTOR B7B–PH–SM3
CN205 8P–VH CONNECTOR B8P–VH
CN111 CONNECTOR B9B–PH–SM3
SCREW BBZ30P080FMC
CN202, CN363 3P PLUG KM200IB3
CN302 4P PLUG KM200IB4
CN201, CN203, CN301, CN351, CN352 KM200IB5
5P PLUG
CN303, CN364 6P PLUG KM200IB6
CN365 7P PLUG KM200IB7
RCC CONTROL A ASSY
SEMICONDUCTORS
IC203 M5233FP
Q208 2SD1835
D220–D223, D225, D227 1SS352
D229–D231, D233 1SS352
D232 D1FL20U (S)
D224, D226 MA700A
D228 UDZ12B
D234 UDZ27B
CAPACITORS
C221 (2.2 µF/DC25V) ACH1278
C222 CEHAT100M50
C223 CEHAT4R7M50
C220 CKSQYB103K50
C218 CQMA103J50
C219 CQMA222J50
Mark No. Description Part No. Mark No. Description Part No.
RESISTORS
R232 RD1/2LMF2R2J
R241 RN1/10SE2702D
R238 RS1/10S1102F
R239 RS1/10S6801F
R242 RS1/10S8201F
R234 RS1/2S151J
R235 RS1/2S471J
R236 RS1/2S472J
R254 RS1LMF3R3J
Other Resistors RS1/10S J
OTHERS
CN207 3P SOCKET KP200IB3L
CN206 5P SOCKET KP200IB5L
RCC CONTROL B ASSY
SEMICONDUCTORS
IC303 M5233FP
Q305 2SD1835
D308–D311, D313, D315 1SS352
D317–D319, D321 1SS352
D320 D1FL20U (S)
D312, D314 MA700A
D316 UDZ12B
D322 UDZ27B
CAPACITORS
C317 (2.2 µF/DC25V) ACH1278
C318, C319 CEHAT4R7M50
C316 CKSQYB103K50
C314 CQMA103J50
C325 CQMA222J50
RESISTORS
R316 RD1/2LMF8R2J
R325 RN1/10SE2702D
R322 RS1/10S1502F
R323 RS1/10S6801F
R326 RS1/10S8201F
R318 RS1/2S151J
R319 RS1/2S471J
R320 RS1/2S472J
R338 RS1LMF1R0J
Other Resistors RS1/10S J
OTHERS
CN308 4P SOCKET KP200IB4L
CN307 5P SOCKET KP200IB5L
To Next Page
