Pioneer PDP-502MX Service Manual

PDP-502MX, PDP-502MXE
59
RCC CONTROL C ASSY
SEMICONDUCTORS
IC353 M5233FP
Q353 2SD1835
D358–D361, D363, D365 1SS352
D367–D369, D371 1SS352
D370 D1FL20U (S)
D362, D364 MA700A
D366 UDZ12B
D372 UDZ27B
CAPACITORS
C367 (2.2 µF/DC25V) ACH1278
C368, C369 CEHAT4R7M50
C365 CKSQYB103K50
C363 CQMA103J50
C364 CQMA822J50
RESISTORS
R364 RD1/2LMF8R2J
R373 RN1/10SE2702D
R370 RS1/10S1502F
R376 RS1/10S6202F
R371 RS1/10S6801F
R374 RS1/10S8201F
R366 RS1/2S151J
R367 RS1/2S471J
R368 RS1/2S472J
R386 RS1LMF1R0J
Other Resistors RS1/10S J
OTHERS
CN361, CN362 5P SOCKET KP200IB5L
OTL CONTROL A ASSY
SEMICONDUCTORS
IC204 TC4538BF
Q210 2SA1037K
Q209, Q211 2SC2412K
D235, D240, D241 1SS352
CAPACITORS
C225 CCSQSL221J50
C224 CKSQYB102K50
RESISTORS
R260 RS1/2S100J
Other Resistors RS1/10S J
OTHERS
CN208 5P SOCKET KP200IB5L
OTL CONTROL B ASSY
SEMICONDUCTORS
IC304 TC4538BF
Q307 2SA1037K
Q306, Q308 2SC2412K
D323–D325 1SS352
CAPACITORS
C321 CCSQSL221J50
C320 CKSQYB102K50
RESISTORS
Other Resistors RS1/10S J
OTHERS
CN309 6P SOCKET KP200IB6L
OTL CONTROL C ASSY
SEMICONDUCTORS
IC354 TC4538BF
Q357 2SA1037K
Q355, Q356 2SC2412K
D374–D376 1SS352
CAPACITORS
C376 CCSQSL331J50
C375 CKSQYB102K50
RESISTORS
Other Resistors RS1/10S J
OTHERS
CN366 7P SOCKET KP200IB7L
VF DD CONVERTER ASSY
SEMICONDUCTORS
IC504 AN1431M
IC503 MIP301
IC501, IC502 TLP181 (GR)
D502 1SS352
D501, D503–D505 D1FL20U (S)
D506 RD15MB
COILS AND FILTERS
T501 ATT1285
CAPACITORS
C507 CEHAT101M25
C509, C510 CEHAT221M25
C506 CEHAT470M25
C508 CEHAT471M16
C501 CEHAT471M35
C502–C505, C511 CKSQYB104K25
Mark No. Description Part No. Mark No. Description Part No.
