Pioneer PDP-502MX Service Manual

PDP-502MX, PDP-502MXE
64
Vertical
Frequency
Fv (Hz)
Holizontal
Frequency
Fh (Hz)
Remarks
Signal Mode
PC
VIDEO
Input Signal
Dot ∗ Line
Panel Display
Dot ∗ Line
OSD
60.0 33.8K Hi-Vision INTERLACE (1035 i ) –– 08-7 1280 ∗ 768 FULL (HD) 08-7+: Y color-difference
HDTV16:9 (1920 ∗ 1080 i ) 08-7: RGB
37.9K 800 ∗ 600 (SVGA) 0A-0 –– 800 ∗ 600 ORIGINAL (VESA: 37.879k/60.317)
38.0K 1072 ∗ 600 (WIDE-SVGA) 0A-1 –– 1024 ∗ 768 4:3NORMAL
0A-2 –– 1280 ∗ 768 FULL
45.0K HDTV16:9 (1280 ∗ 720 p ) –– 0B-7 1280 ∗ 768 FULL (HD) 0B-7+: Y color-difference
0B-7: RGB
48.4K 1024 ∗ 768 (XGA) 0C-1 –– 1024 ∗ 768 ORIGINAL (VESA: 48.363k/60.004)
48.0K 1376 ∗ 768 (WIDE-XGA) 0C-2 –– 1280 ∗ 768 FULL
53.7K 1152 ∗ 864 0D-1 –– 1024 ∗ 768 4:3 (TYPE)
0D-2 –– 1280 ∗ 768 FULL (TYPE)
60.0K 1280 ∗ 960 0E-1 –– 1024 ∗ 768 4:3 (TYPE) (VESA: 60.000k/60.000)
0E-2 –– 1280 ∗ 768 FULL (TYPE)
64.0K 1280 ∗ 1024 (SXGA) 0F-1 –– 960 ∗ 768 4:3 (TYPE) (VESA: 63.981k/60.020)
64.3K 0F-2 –– 1280 ∗ 768 FULL (TYPE)
64.6K 0F-3 –– 1280 ∗ 768 ZOOM Trimming display
67.5K Hi-Vision PROGRESSIVE (1035 p) –– 10-7 1280 ∗ 768 FULL (HD) 10-7+: Y color-difference
HDTV16:9 (1920 ∗ 1080 p ) 10-7: RGB
75.0K 1600 ∗ 1200 (UXGA) 11-1 –– 1024 ∗ 768 4:3 (TYPE) (VESA: 75.000k/60.000)
65.0 81.3K 1600 ∗ 1200 (UXGA) 12-1 –– 1024 ∗ 768 4:3 (TYPE) (VESA: 81.250k/65.000)
66.7 35.0K 640 ∗ 480 (Macintosh 13) 14-0 –– 640 ∗ 480 ORIGINAL
14-1 –– 1024 ∗ 768 4:3 NORMAL
14-2 –– 1280 ∗ 768 FULL
62.0K 1152 ∗ 900 (SUN LO) 13-1 –– 1024 ∗ 768 4:3 (TYPE) Mode for SUN (UNIX)
13-2 –– 1280 ∗ 768 FULL (TYPE)
70.1 31.5K 640 ∗ 400 (PC-H98) 15-2 –– 1280 ∗ 768 FULL 720 ∗ 400 can be displayed
(Data amount drops)
56.5K 1024 ∗ 768 (XGA) 16-1 –– 1024 ∗ 768 ORIGINAL (VESA: 56.476k/70.069)
16-2 –– 1280 ∗ 768 FULL
87.5K 1600 ∗ 1200 (UXGA) 17-1 –– 1024 ∗ 768 4:3 (TYPE) (VESA: 87.500k/70.000)
72.0 37.9K 640 ∗ 480 (VGA) 18-0 –– 640 ∗ 480 ORIGINAL (VESA: 37.861k/72.809)
18-1 –– 1024 ∗ 768 4:3 NORMAL
18-2 –– 1280 ∗ 768 FULL
48.1K 800 ∗ 600 (SVGA) 19-0 –– 800 ∗ 600 ORIGINAL (VESA: 48.077k/72.188)
19-1 –– 1024 ∗ 768 4:3 NORMAL
19-2 –– 1280 ∗ 768 FULL
64.9K 1152 ∗ 864 1A-1 –– 1024 ∗ 768 4:3 (TYPE)
1A-2 –– 1280 ∗ 768 FULL (TYPE)
75.0 37.5K 640 ∗ 480 (VGA) 1C-0 –– 640 ∗ 480 ORIGINAL (VESA:37.500k/75.000)
1C-1 –– 1024 ∗ 768 4:3 NORMAL
1C-2 –– 1280 ∗ 768 FULL
46.9K 800 ∗ 600 (SVGA) 1D-0 –– 800 ∗ 600 ORIGINAL (VESA:46.875k/75.000)
1D-1 –– 1024 ∗ 768 4:3 NORMAL
1D-2 –– 1280 ∗ 768 FULL
(74.6) 49.7K 832 ∗ 624 (Macintosh 16) 1E-0 –– 832 ∗ 624 ORIGINAL 4:3/FULL = Top & bottom
1E-1 –– 1024 ∗ 748 4:3 NORMAL
are masked
1E-2 –– 1280 ∗ 748 FULL
