Pioneer PDP-502MX Service Manual

PDP-502MX, PDP-502MXE
65
Vertical
Frequency
Fv (Hz)
Holizontal
Frequency
Fh (Hz)
Remarks
Signal Mode
PC VIDEO
Input Signal
Dot ∗ Line
Panel Display
Dot ∗ Line
OSD
75.0 60.0K 1024 ∗ 768 (XGA) 1F-1 –– 1024 ∗ 768 ORIGINAL (VESA: 60.023k/75.029)
(74.9) 60.2K 1024*768 (Macintosh 19) 1F-2 –– 1280 ∗ 768 FULL 74.9/60.2K.......MAC
67.7K 1152 ∗ 864 20-1 –– 1024 ∗ 768 4:3 (TYPE) (VESA: 67.500k/75.000)
20-2 –– 1280 ∗ 768 FULL (TYPE)
(75.1) 68.7K 1152 ∗ 870 (Macintosh 21) 21-1 –– 1024 ∗ 768 4:3 (TYPE)
21-2 –– 1280 ∗ 768 FULL (TYPE)
(76.1) 71.7K 1152 ∗ 900 (SUN HI) 2A-1 –– 1024 ∗ 768 4:3 (TYPE)
2A-2 –– 1280 ∗ 768 FULL (TYPE)
80.0K 1280 ∗ 1024 (SXGA) 22-1 –– 960 ∗ 768 4:3 (TYPE) (VESA: 79.976k/75.025)
81.0K 1600 ∗ 1024 (WIDE-SXGA)
85.0 43.3K 640 ∗ 480 (VGA) 23-0 –– 640 ∗ 480 ORIGINAL (VESA: 43.269k/85.008)
23-1 –– 1024 ∗ 768 4:3NORMAL
23-2 –– 1280 ∗ 768 FULL
53.7K 800 ∗ 600 (SVGA) 24-0 –– 800 ∗ 600 ORIGINAL (VESA: 53.674k/85.061)
24-1 –– 1024 ∗ 720 4:3NORMAL 4:3/FULL = Top & bottom
24-2 –– 1280 ∗ 720 FULL
are masked
68.7K 1024 ∗ 768 (XGA) 25-1 –– 1024 ∗ 768 ORIGINAL (VESA: 68.677k/84.997)
25-2 –– 1280 ∗ 768 FULL
91.1K 1280 ∗ 1024 (SXGA) 26-1 –– 960 ∗ 768 4:3 (TYPE) (VESA: 91.146k/85.024)
87.0 35.5K 1024 ∗ 768 (XGA) 27-1 –– 1024 ∗ 768 ORIGINAL (TYPE) (VESA: 35.522k/43.479
INTERLACE 27-2 –– 1280 ∗ 768 FULL (TYPE)
INTERLACED)
46.4K 1280 ∗ 1024 (SXGA) 28-2 –– 1280 ∗ 768 FULL (TYPE)
