PDP-502MX
84
Service Position
1. MAIN POWER ASSY
1
3
2
1
MAIN POWER ASSY
VIDEO ASSY
Remove
two screws
Remove
two screws
Loosen two screws
Remove the harness from
Wire Saddle
4
5
MAIN POWER ASSY
MAIN POWER ASSY
Stand Main Power Assy
