PDP-502MX, PDP-502MXE
96
Î
VIDEO
INPUT
Y/C
VOL
MENU
STANDBY
/ON
SCREEN
MUTING
DISPLAY
RGB
(D-sub)
SET
RGB
(BNC)
12
34
SIZE
8
9
7
6
2
3
4
5
1
1 STANDBY/ON button
Press to put the unit in operation or standby mode.
2 INPUT buttons
Use to select the input.
3 MENU button
Press to open and close the on-screen menu.
4 ADJUST (5/∞/3/2) buttons
Use to navigate menu screens and to adjust various
settings on the unit.
Usage of cursor buttons within operations is clearly
indicated at the bottom the on-screen menu display.
5 SET button
Press to adjust or enter various settings on the unit.
6 SCREEN SIZE button
Press to manually select the screen size.
7 MUTING button
Press to mute the volume.
8 VOL (+/–) buttons
Use to adjust the volume.
9 DISPLAY button
Press to view the unit’s current input and setup mode.
Remote Control Unit (for PDP-502MX and PDP-502MXE)
