PDP-502MX, PDP-502MXE
97
SPECIFICATIONS
General
Light emission panel ............ 50 inch plasma display panel
Number of pixels.............................................. 1280 x 768
Power supply ............................. AC 100 - 120 V, 50/60 Hz
Power consumption ................................................ 470 W
Standby power consumption ................................... 0.6 W
External dimensions........ 1218 (W) x 714 (H) x 98 (D) mm
.............................47-31/32 (W) x 28-1/8 (H) x 3-7/8 (D) in.
(when using table top stand)
...................................... 1218 (W) x 737 (H) x 300 (D) mm
..................... 47-31/32 (W) x 29-1/32 (H) x 11-13/16 (D) in.
Weight............................................... 39.7 kg (87 lbs. 9 oz)
(including table top stand) ................ 40.5 kg (89 lbs. 5 oz)
Operating temperature range ..... 0 to 40 °C (32 to 104 °F)
Operating atmospheric pressure range
........................................ 0.8 to 1.1 atmospheric pressure
Input/output
Video
INPUT 1
Input BNC jack
• Composite video signal
1 Vp-p/75 Ω/negative sync.
Output BNC jack
75 Ω /with buffer
INPUT 2
Input 1 S terminal (Mini DIN 4 pin)
2 BNC jack (x2)
• Y/C saparate video signal (S2 compatible)
Y . . . 1 Vp-p/75 Ω/negative sync.
C . . .0.286 Vp-p/75 Ω (NTSC)
0.3 Vp-p/75 Ω (PAL)
INPUT 3
Input BNC jack (x5)
1 RGB signal (G ON SYNC compatible)
RGB ... 0.7 Vp-p/75 Ω/no sync.
HD/CS, VD ... TTL level
/positive and negative polarity/
75 Ω or 2.2 kΩ
(impedance switch)
G ON SYNC ...
1 Vp-p/75 Ω/negative sync.
2 Component video signal
Y ... 1 Vp-p/75 Ω/negative sync.
C
B/PB, CR/PR
... 0.525 Vp-p/75 Ω
(75% satulation level)
INPUT 4
Input Mini D-sub 15 pin (socket connector)
1 RGB signal (G ON SYNC compatible)
RGB ... 0.7 Vp-p/75 Ω/no sync.
HD/CS, VD ... TTL level
/positive and negative polarity
/2.2 kΩ
G ON SYNC
... 1 Vp-p/75 Ω/negative sync.
*Compatible with Microsoft’s Plug & Play
(VESA DDC1/2B)
2 Component video signal
Y ... 1 Vp-p/75 Ω/negative sync.
C
B/PB, CR/PR
... 0.525 Vp-p/75 Ω
(75% satulation level)
Output Mini D-sub 15 pin connector (socket)
75 Ω/with buffer
Audio
Input AUDIO INPUT (for INPUT 1/2)
Pin jack (x2)
L/R ... 500mVrms/more than 47 kΩ
AUDIO INPUT (for INPUT 3/4)
Stereo mini jack
L/R ... 500mVrms/more than 47 kΩ
Output AUDIO OUTPUT
Stereo mini jack
L/R ... 500mVrms (max)/less than 5 kΩ
SPEAKER
L/R ... 8 – 16 Ω/2W +2W (at 16 Ω)
Control
RS-232C... D-sub 9 pin (pin connector)
COMBINATION IN/OUT
... Mini DIN 6 pin (x2)
CONTROL IN/OUT ... monaural mini jack (x2)
Accessories
Power cord....................................................................... 1
Pin/BNC conversion adaptor ............................................ 1
Remote control unit ......................................................... 1
Remote control unit case ................................................. 1
AA (R6/UM-3) batteries.................................................... 2
Cleaning cloth................................................................... 1
Speed clamp .................................................................... 2
Bead band ........................................................................ 2
Warranty........................................................................... 1
Operations Instructions.................................................... 1
Display stand.................................................................... 2
Washer (large) .................................................................. 2
Washer (small) ................................................................. 2
Hex hole bolt (M8X40) ..................................................... 2
÷ Due to improvements, specifications and design are subject to
change without notice.
