PDP-503PE, PDP-503PU
Display example of the thirteenth page
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
VI
PC
DDEEO
NEGAT
21/13 PUT1NoSIGNI
DR 0 0VE MOI
DEDR VE MO
DEMO
I
VEI
PATT E NR
ENHAN ECBR I GHT
FREQMA SK
FULL MASK
MASK
V
03
OFF
OFF
OFF
OFF
50
No. Item Adjustable Range Shipping Setting Storage Place
1 Drive mode selection at VIDEO 0 to 5 0 PDP
2 Drive mode selection at PC 0 to 5 3 PDP
3 Negative positive inversion mode OFF/ON OFF PDP
4 Bright enhance OFF/ON OFF None
5 Refresh rate at mask signal generation 50/60/70 – None
6 Pattern mask signal generation OFF/ OFF PDP
7 Full mask signal generation OFF/ OFF PDP
Caution in the mask (generation test signal screen in the PDP inside) signal generation:
• A pattern mask and a full mask can use only either.
Therefore, turn a full mask to OFF when uses a pattern mask. Also turn a pattern mask to OFF when uses a full mask.
• A pattern mask and a full mask are test signal screens occurring together in the PDP inside. Therefore, in the mask signal generation, it
cannot confirm video inputting from OSD and the outside.
When release mask setting or change of each setting or perform the confirmation of the adjustment or external input signal, perform key
operation of the main unit button or the remote control unit.
When operated something, stop the generation of the mask signal just after that for two seconds. Therefore, modification and adjustment of
each setting and confirmation of the external input signal are possible.
∗ : Be careful so that there is the case that page constitution is different.
