88
PDP-503PE, PDP-503PU
1
Remove the Rear Case (50P). (Screws × 19)
2
Remove the X DRIVE Assy. (Connector, Screws × 8)
X DRIVE Assy
×2
2
×2
2
×2
2
×2
2
X DRIVE Assy
