Pin Function (2/3)
AN16003A-K (50 SCAN A ASSY : IC3001 - IC3006)
(50 SCAN B ASSY : IC3201 - IC3206)
Plasma Display Panel IC
51 OUT39
52 OUT40
53 OUT41
54 OUT42
55 OUT43
56 OUT44
57 OUT45
58 OUT46
59 OUT47
60 OUT48
61 OUT49
62 OUT50
63 OUT51 Output High-voltage push-pull output pin
64 OUT52
65 OUT53
66 OUT54
67 OUT55
68 OUT56
69 OUT57
70 OUT58
71 OUT59
72 OUT60
73 OUT61
74 OUT62
75 OUT63
76 OUT64
77 N.C - Not connected
78 V
DDH Supply High-voltage circuit supply pin
79 V
DDH Supply High-voltage circuit supply pin
80 N.C - Not connected
81 GND Ground GND pin
82 GND Ground GND pin
83 GND Ground GND pin
Setup pin of sift register sift direction
84 DIR Input L: Shift into reverse (SO = SI)
H: Shift forward (SI = SO)
85 SO Input/Output Serial data input/output pin
Serial clock input pin
86 CLK Input Fetch SI or SO data to sift register
by CLK rise edge
LAT data input pin
87 LAT Input L: Transfer shft register data to output latch
H: Hold data to output latch
88 VDD Supply Logic supply pin
89 OC1 Output control pin
Input Control output according to the right
truth value table
90 OC2
OC1 OC2 OUT
LLALL HiZ
LHDATA
HLALL L
HHALL H
Pin No. Pin Name Type Discription
