PDP-504PU
97
5 678
56
7
8
C
D
F
A
B
E
Pin Function (3/3)
AN16003A-K (50 SCAN A ASSY : IC3001 - IC3006)
(50 SCAN B ASSY : IC3201 - IC3206)
Plasma Display Panel IC
91 SI Input/Output Serial data input/output pin
All output reset pin
92 CLK Input CLK pin: L = Normal operation
CLK pin: H = All output High
93 GND Ground GND pin
94 GND Ground GND pin
95 GND Ground GND pin
96 N.C - Not connected
97 VDDH Supply High-voltage circuit supply pin
98 VDDH Supply High-voltage circuit supply pin
99 OUT1 Output High-voltage push-pull output pin
100 OUT2 Output High-voltage push-pull output pin
Pin No. Pin Name Type Discription
