7.3 ADJUSTMENT REQUIRED WHEN PART IS REPLACED
The assembly must be replaced as a unit, and no
part replacement is allowed.
POWER SUPPLY Unit
MAIN Assy (*)
60 DIGITAL Assy
No adjustment is required after replacement of parts
other than those mentioned above.
No adjustment is required after replacement of parts
other than those mentioned above.
No adjustment is required after replacement of parts
other than those mentioned above.
60 X DRIVE Assy
60 Y DRIVE Assy
No adjustment required
TANSHI Assy
60 ADDRESS Assy No adjustment required
SENSOR Assy
Notes on replacing parts
For the parts described in the list below, replacement is required for the whole Assy, not only the defective part.
If any part listed below is identified as defective and needs replacement, replace the whole Assy, and make necessary
adjustments after replacement.
Reason: The whole Assy must be replaced, because adjustments and data rewriting for the Assy at the level of production
line are required.
PCB Assy No. Function Name
Parts that Require Whole-Assy Replacement
Ref No. Function Name Part No.
AWW1190 60 DIGITAL Assy
IC3151 Module microcomputer AGC1011
IC3401 Sequence IC PEG122C
IC3301 Flash memory AGC1026
IC3156 EEPROM BR24L04FJ-W
AWW1191 SENSOR Assy IC3652 EEPROM BR24L02FJ-W
AWV2312 MAIN Assy
IC5101 Main VDEC UPD64015GM-UEU
IC5301 A/D converter AD9985KSTZ-110
IC4701 AV switch R2S11002AFT
IC4901 RGB switch R2S11001FT
IC6201 System IC BCM3517KQLGB0
IC6602 DDR-SDRAM EDD2516AKTA-6B
IC6603 DDR-SDRAM EDD2516AKTA-6B
IC6604 DDR-SDRAM EDD2516AKTA-6B
IC6605 DDR-SDRAM EDD2516AKTA-6B
IC6902 NOR Flash AGC1008
IC8202 Flash ROM AGC1007
IC8402 Flash ROM AGC1006
(*) : When replacing the MAIN Assy, be sure to do the FINAL SETUP.
Refer to "7.6 ADJUSTMENTS WHEN THE DRIVE
ASSY ARE REPLACED".
Assy Ref. No. Part Category Part No.
60
X DRIVE Assy
IC1206 Photo Coupler PS9117-TLB
IC1207 FET Driver TND307TD-TBB
IC1210 FET Driver TND307TD-TBB
60
Y DRIVE Assy
IC2242 Photo Coupler PS9117-TLB
IC2241 FET Driver TND307TD-TBB
IC2252 FET Driver TND307TD-TBB
After any of the parts shown below on the 60 X DRIVE
or 60 Y DRIVE Assy are replaced, a waveform adjustment
is required.
Object parts
