9.3.10 QSI
14: Detection of existence of H
N No H
YH detected
18 to 20: Each protection
operation status
0 Setting OFF
1 Setting ON (waiting)
2 Setting ON (during operation)
22: Transition of brightness by
protection operation
0 Upper limit state for brightness
1 Brightness being reduced
2 Lower limit state for brightness
3 Brightness being increased
Data Arrangement
Data
Length
Output Example
ECO 3 Byte QSI
1 Type of drive sequence 3 Byte 60V
2 Standard/nonstandard 1 Byte S
3 Type of ABL/WB tables 2 Byte T1
4 Total value of PCN 4 Byte 0256
5 Total value of PRH 4 Byte 0256
6 Total value of PGH 4 Byte 0256
7 Total value of PBH 4 Byte 0256
8 Total value of PBR 4 Byte 0512
9 Total value of PRL 4 Byte 0512
10 Total value of PGL 4 Byte 0512
11 Total value of PBL 4 Byte 0512
12 Total value of ABL 3 Byte 128
13 Detection of V frequency 4 Byte 6002
14 Detection of existence of H 1 Byte Y
15 Reserved 3 Byte ∗∗∗
16 Obtained APL data 4 Byte 1023
17 Number of SUS pulses 4 Byte 0457
18 Result of detection of still picture 1 Byte 1
19 Result of detection of cracking in the panel 1 Byte 1
20 Result of detection for scanning protection 1 Byte 1
21 Result of detection for external protection 1 Byte 1
22 Transition of protection operation 1 Byte 0
23 Reserved 4 Byte ∗∗∗∗
CS 2 Byte 27
Command
Format
Effective Operation
Modes
Function Remarks
[QSI] All operations
To acquire all data on input video signals
Return data: 3 (ECO)+66(DATA)+2(CS)= 71 Byte
7 Acquisition of input signal data • • • [QSI]
The command QSI is for acquiring all data on input video signals.
