(1) REAR SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-6071PU/KUC, KUCXC, PDP-6070PU/KUC and KUCXC types are constructed the same except for the following:
Mark
No. Description Part No.
1 SIDE KEY Assy AWW1133
2 SIDE Assy AWW1157
3 USB Cable (J301)(120 cm) ADF1034
4 Side Input Panel (U) ANC2392
5 Function Button Base ANG2923
6 Side Input Shield ANK1834
7 Function Button Shield ANK1835
NSP 8 PCB Support AEC1288
9 PCB Spacer AEC1570
10 Re-use Wire Saddle AEC1945
11 Locking Wire Saddle AEC1948
12 Locking Card Spacer AEC2019
13 USB Spacer AED1310
14 Handle AMR3564
15 Gasket (USB) ANK1846
NSP 16 Name Label See Contrast table (2)
17 Serial Seal See Contrast table (2)
18 Caution Label See Contrast table (2)
19 Terminal Display Label A (U/B) AAX3325
20
Ter minal Display Label B50 (U/B)
AAX3414
21 Under Cover (60) ANC2433
22 Function Button Panel AMB2906
23 Side Input Cover AMB2911
24 Function Button AAC1562
25 Function Button Sheet (U) AAK2895
26 Input Cover Label U AAX3363
27 Sub Frame Cover L AMR3586
28 Sub Frame Cover R AMR3587
29 Rear Case (607) ANE1657
30 • • • • •
31 Screw ABA1341
32 Screw AMZ30P060FTB
33 Screw AMZ30P080FTC
34 Screw APZ30P100FTB
35 Screw APZ40P100FTB
36 Screw BPZ30P080FTB
37 Screw PMB30P100FTB
38 Screw PMB40P120FTB
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-6071PU
/KUC
PDP-6071PU
/KUCXC
PDP-6070PU
/KUC
PDP-6070PU
/KUCXC
NSP 16 Name Label AAL2786 AAL2839 AAL2840 AAL2841
17 Serial Seal AAX3143 Not used AAX3143 Not used
NSP 17 Serial Seal Not used AAX3182 Not used AAX3182
18 Caution Label AAX3393 AAX3430 AAX3393 AAX3430
To Next Page
