PDP-6071PU
199
5678
56
7
8
C
D
F
A
B
E
1
PC INPUT terminal (ANALOG RGB)
CableCARD™ slot
ANT/CABLE A IN terminal
ANT B IN terminal
AC IN terminal
HDMI terminals (INPUT 5/INPUT 6)
RS-232C terminal (used for factory setup)
DIGITAL OUT terminal (OPTICAL)
G-LINK terminal
10
INPUT 5 terminals (AUDIO)
11
INPUT 6 terminals (AUDIO)
12
SUB WOOFER terminal
13
INPUT 3 terminals (AUDIO)
14
INPUT 3 terminals (COMPONENT VIDEO: Y,
C
B
/P
B
, C
R
/P
R
)
15
INPUT 2 terminals (COMPONENT VIDEO: Y,
C
B
/P
B
, C
R
/P
R
)
16
INPUT 2 terminal (VIDEO)
17
INPUT 2 terminal (S-VIDEO)
18
INPUT 2 terminals (AUDIO)
19
INPUT 1 terminals (AUDIO)
20
INPUT 1 terminal (S-VIDEO)
21
INPUT 1 terminal (VIDEO)
22
MONITOR OUT terminal (VIDEO)
23
MONITOR OUT terminals (AUDIO)
24
PC INPUT terminal (AUDIO)
25
CONTROL OUT terminal
26
SPEAKER (R/L) terminals
27
Stand: PDK-TS15 for the PDP-6072HD
PDK-TS15U for the PDP-6071HD/
PDP-6070HD
28
Speaker: PDP-S41
For details, refer to the operation manual that
came with the stand or speaker.
1 2
3
76 8
9
25
26
24
15
12
13
10
11
14
16
20
17 21
22
18 1923
4
5
28
27
Rear view
(Terminals located on the upper
edge of the compartment)
(PDP-6072HD/PDP-6071HD/PDP-6070HD)
To Next Page
