Pioneer PDP-6071PU - Page 204

PDP-6071PU
204
1234
1234
C
D
F
A
B
E
IN
EN
OUT
FLG
GATE
CONTROL
CURRENT
LIMIT
FLAG
DELAY
UVLO
THERMAL
SHUTDOWN
GND
54
123
1
Pin No. Name
Function
EN Enable terminal
GND terminal
FLAG terminal (Open-drain output)
Power input terminal
Output terminal
2GND
3 FLG
4IN
5OUT
R5520H001B (MAIN ASSY : IC7105)
BLOCK DIAGRAM
• USB HIGH-SIDE SW IC
PIN LAYOUT PIN FUNCTION
