PDP-6071PU
79
5678
56
7
8
C
D
F
A
B
E
Y6: CN2354 (AKM1281) AD2: CN1801 (AKM1291)
60 Y DRIVE ASSY
60 ADDRESS L/S ASSY
Y8: CN2356 (AKM1281) AD2: CN1601 (AKM1291)
Pin No. Name Voltage [V] Name Pin No. Function
1 GND_D 0 GND_D 1 GND
2 5V 5 5V 2 5V power supply
3 8V 8 8V 3 8V power supply
4 GND_ADR 0 GND_ADR 4 GND
5 +60V 60 +60V 5 60V power supply
6 +60V 60 +60V 1 60V power supply
7 GND_ADR 0 GND_ADR 2 GND
8 8V 8 8V 3 8V power supply
9 5V 5 5V 4 5V power supply
10 GND_D 0 GND_D 5 GND
Y2: CN2402 (AKM1200) SB1: CN2901 (AKP1261)
60 Y DRIVE ASSY
607 SCAN B ASSY
Pin No. Name Voltage [V] Name Pin No. Function
1 VH 130 VH 1 Power supply for VH
2 VH 130 VH 2 Power supply for VH
3NC -NC 3 Non-connection termial
4 NC - NC 4 Non-connection termial
5 NC - NC 5 Non-connection termial
6 GNDH -60 300 GNDH 6 GND(PSUS)
7 SI_H -60 300 SI_H 7 SI_H signal
8 CLR -60 300 CLR 8 CLR signal
9 OC2 -60 300 OC2 9 OC2 signal
10 OC1 -60 300 OC1 10 OC1 signal
11 CLK1 -60 300 CLK1 11 CLK1 signal
12 LE -60 300 LE 12 LE signal
13 GNDH -60 300 GNDH 13 GND(PSUS)
14 GNDH_R -60 300 GNDH_R 14 GND(PSUS). Connector detection
15 IC5V -60 300 IC5V 15 IC5V power supply
