Mark No. Description Part No.
Mark No. Description Part No.
TRANS2 ASSY
SEMICONDUCTORS
IC351, IC352 (5A) AEK7019
IC353 (2.5A) ICP-N70
D356 MTZJ20A
D357 MTZJ9.1B
D354, D355 S5688G
CAPACITORS
C350–C354, C360, C361 (1µF/100V) ACH1237
C362 CEANP470M25
C359 CEAT101M10
C358 CEAT101M35
C357 CEAT470M50
RESISTORS
R350–R352 RD1/4PMF100J
R353 RFA1/4PS4R7J
R358 RS1LMF182J
Other Resistors RD1/4PU&&&J
OTHERS
352, 353 5P CABLE HOLDER 51048-0500
356 4P CABLE HOLDER 51052-0400
351 6P CABLE HOLDER 51052-0600
J9 JUMPER WIRE 5P D20PYY0545E
CN354, CN355 4P PLUG KM200TA4
357, 358 PCB BINDER VEF1040
TRANS1 ASSY
OTHERS
J51 LEAD WIRE UNIT DB035NB0
J52 LEAD WIRE UNIT DB135NB0
BARRIER ASSY
OTHERS
CN681, CN682 4P SOCKET KP200TA4L
FET ASSY
SEMICONDUCTORS
Q1452 IRF540A
Q1451 IRF9540A
RESISTORS
R1451, R1452 RD1/4PMF101J
Other Resistors RD1/4PM&&&J
OTHERS
1451 10P CABLE HOLDER 51052-1000
MECH SW ASSY
SWITCHES AND RELAYS
S376 ASG7014
CAPACITORS
C376, C377 CKCYF103Z50
OTHERS
CN376 3P JUMPER HOLDER 52151-0310
VIDEO ASSY
SEMICONDUCTORS
IC501 NJM2296D
IC502, IC503 UPC4570C
Q502 2SA1515
Q505 2SA933S
Q501 2SC3377
Q506 KRC103M
D503, D505–D510 1SS133
D501, D502 MTZJ6.2B
CAPACITORS
C540–C543 CCCSL101J50
C505–C507, C536–C539 CCCSL221J50
C501–C504, C511, C512, C535 CEAT470M25
C517, C518, C521, C522 CEAT4R7M50
C545, C546 CEHAT470M25
C509, C510 CGCYX473M25
C513, C514, C523–C526 CKCYF103Z50
C531–C533 CKCYF103Z50
RESISTORS
R510, R511 RS1LMF151J
Other Resistors RD1/4PU&&&J
OTHERS
CN507 17P FFC CONNECTOR 52045-1745
502 2P PIN JACK AKB7017
JA501 3P PIN JACK AKB7056
CN504 4P PIN JACK AKB7087
JA505, JA506 REMOTE CONTROL JACK RKN1004
SVIDEO ASSY
SEMICONDUCTORS
IC551, IC552 NJM2296D
Q554 2SA1515
Q551 2SA933S
Q552 2SC1740S
Q553 2SC3377
D555, D556, D559, D560 1SS133
D557, D558 MTZJ6.2B
CAPACITORS
C570–C575 CCCSL221J50
C578, C579 CEAT470M10
C551, C555, C559, C563 CEAT470M25
C590, C591 CEAT470M25
C593, C594 CEHAT470M25
C552, C556, C560, C564, C567 CGCYX104M16
C580–C582 CGCYX104M16
C553, C557, C561, C565 CGCYX473M16
C576, C577 CGCYX473M16
C585, C587 CKCYF103Z50
