45
VSA-E03
Mark No. Description Part No.
Mark No. Description Part No.
C554, C558, C562, C566 CKPUYY103M16
C568, C569 CKPUYY103M16
RESISTORS
R583, R584 RS2LMF101J
Other Resistors RD1/4PU&&&J
OTHERS
CN554 11P FFC CONNECTOR 52044-1145
CN552 4P MINI DIN SOCKET AKP7020
CN551 4P MINI DIN SOCKET AKP7043
CN555 KR CONNECTOR 3P B3B-PH-K-S
FRONT VIDEO ASSY
CAPACITORS
C601, C602 CCCSL221J50
C604, C608 CEAT470M25
C605–C607 CGCYX104M25
C603 CGCYX473M25
C609, C610 CKCYB471K50
C611, C612 CKCYF103Z50
RESISTORS
All Resistors RD1/4PU&&&J
OTHERS
CN601 FRONT PIN JACK AKX7007
601 PCB BINDER VEF1040
DOLBY DIGITAL ASSY
SEMICONDUCTORS
IC9401 CS4226-KQ
IC9322 CY62256VLL-70SNC
IC9321 MB86342B
IC9201 NJM2100M
IC9602–IC9604, IC9701–IC9705 NJM4558MD
IC9391 PQ20WZ51
IC9151 TC74ACT151F
IC9101 TC74HCU04AF
IC9301 TC74LVX244FT
IC9311 TC74VHCT244AFT
IC9601 TC9164AF
Q9201, Q9202, Q9601–Q9606 2SC3326
Q9615, Q9616 2SC3326
Q9203, Q9325, Q9402, Q9607 DTA124EK
Q9609, Q9610, Q9613, Q9614 DTA124EK
Q9204, Q9321, Q9322, Q9324, Q9401 DTC124EK
Q9608, Q9611, Q9612 DTC124EK
D9601, D9602 1SS181
COILS AND FILTERS
L9321, L9391, L9807, L9809 ATL7002
CHIP FERRITE BEAD
L9101, L9102, L9151, L9301, L9311 QTL1013
CHIP SOLID INDUCTOR
L9323, L9402, L9403, L9801–L9805 QTL1013
CHIP SOLID INDUCTOR
CAPACITORS
C9159, C9201, C9202, C9324, C9329 CCSRCH101J50
C9331, C9334, C9336, C9338, C9342 CCSRCH101J50
C9420, C9736 CCSRCH102J50
C9326, C9327 CCSRCH120J50
C9377, C9707, C9708, C9721, C9722 CCSRCH151J50
C9735 CCSRCH151J50
C9408, C9409 CCSRCH180J50
C9323, C9369, C9370, C9609, C9610 CCSRCH221J50
C9621, C9622 CCSRCH221J50
C9108, C9154, C9303, C9313, C9413 CCSRCH271J50
C9629 CCSRCH271J50
C9428, C9429 CCSRCH331J50
C9418, C9419 CCSRCH390J50
C9307–C9310, C9315, C9316, C9368 CCSRCH471J50
C9405, C9414, C9422–C9426, C9431 CCSRCH471J50
C9601, C9602, C9605, C9606 CCSRCH471J50
C9613, C9614, C9617, C9618, C9625 CCSRCH471J50
C9639 CCSRCH471J50
C9104 CCSRCH560J50
C9105, C9109, C9151, C9301, C9311 CEJA101M10
C9340, C9393, C9401, C9402, C9415 CEJA101M10
C9801 CEJA101M10
C9410 CEJA1R0M50
C9803, C9805 CEJA220M25
C9207, C9321 CEJA221M6R3
C9391 CEJA4R7M50
C9205, C9206 CEJANP100M10
C9433 CEJAR47M50
C9713, C9714, C9727, C9728 CEWAR220M25
C9739, C9740 CEWAR220M25
C9203, C9204, C9603, C9604 CEWAR4R7M50
C9615, C9616, C9627, C9628 CEWAR4R7M50
C9407 CKSQYB224K16
C9101, C9107, C9153, C9302, C9312 CKSRYB103K50
C9626, C9636, C9637, C9642 CKSRYB103K50
C9158, C9705, C9706, C9719, C9720 CKSRYB104K16
C9733, C9734 CKSRYB104K16
C9633 CKSRYB122K50
C9703, C9704, C9717, C9718, C9731 CKSRYB222K50
C9406 CKSRYB223K50
C9701, C9702, C9715, C9716, C9729 CKSRYB682K50
C9732 CKSRYB682K50
C9102, C9115, C9116, C9119 CKSRYF104Z16
C9208, C9209, C9325, C9330, C9332 CKSRYF104Z16
C9335, C9337, C9339, C9341, C9404 CKSRYF104Z16
C9421, C9427, C9432, C9607, C9608 CKSRYF104Z16
C9619, C9620, C9631, C9632 CKSRYF104Z16
C9709–C9712, C9723–C9726 CKSRYF104Z16
C9737, C9738, C9807 CKSRYF104Z16
RESISTORS
R9393 RS1/16S2001F
R9391 RS1/16S5600F
Other Resistors RS1/16S&&&J
